ADF

M018/M019 4-68 SM

4.12.11 ADF FEED SENSOR

1. ADF unit ( p.4-60)

2. ADF feed unit ( p.4-62)

3. Sensor cover [A] ( x 2)

4. ADF feed sensor [B] (hooks)
