Installing the Machine
37
2
O Using both hands, hold the center of the top cover and close the cover care-
fully. Be careful not to trap your fingers.
After closing the top cover, wait until the initial screen is displayed.
Turning the Power on
This section describes how to turn on the machine.
R
WARNING:
Important
❒ Make sure that the power cord is plugged securely into the wall outlet before
turning the power on.
❒ Make sure that the power is off when plugging or unplugging the power
cord.
❒ Do not turn off the power switch until initializing is completed. Doing so re-
sults in malfunction.
A Plug in the power cord.
• Plug and unplug the power cable with dry hands, or an electric shock
could occur.
BPC044S
BAA042S

Table of Contents

Other manuals for Ricoh Aficio SP C231SF

Preview: Service Manual
Service Manual292 pages
Preview: Information
Information36 pages
Preview: Specifications
Specifications4 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh Aficio SP C231SF and is the answer not in the manual?

Ricoh Aficio SP C231SF Specifications

Aficio SP C231SF

Engine Specifications IconEngine Specifications
print resolution600 x 600 dpi (Speed mode), 1200 x 600 dpi equivalent (Standard Mode), 2400 x 600 dpi equivalent (Fine Mode)
output speed21 pages-per-minute in B&W and Full-Color
first print speed14 seconds or less
warm-up time48 seconds or less
Power IconPower
power requirements120V, 60Hz
maximum power consumption1, 300W
energy saver mode20W
System Memory IconSystem Memory
memory (ram)128 MB RAM standard/maximum
standard interfacesUSB 2.0, 10/100Base-TX Ethernet
optional interfaceIEEE 802.11b/g Wireless
Weight and Dimensions IconWeight and Dimensions
dimensions16.54" x 19.41" x 18.74" (420 x 493 x 476 mm)
weight66.14 lb. (30 kg or less)

Aficio SP C232SF

Engine Specifications IconEngine Specifications
print resolution600 x 600 dpi (Speed mode), 1200 x 600 dpi equivalent (Standard Mode), 2400 x 600 dpi equivalent (Fine Mode)
output speed21 pages-per-minute in B&W and Full-Color
first print speed14 seconds or less
warm-up time48 seconds or less
Power IconPower
power requirements120V, 60Hz
maximum power consumption1, 300W
energy saver mode25W
System Memory IconSystem Memory
memory (ram)256 MB RAM standard/512 MB RAM maximum (shared)
standard interfacesUSB 2.0, 10/100Base-TX Ethernet
optional interfaceIEEE 802.11b/g Wireless
Weight and Dimensions IconWeight and Dimensions
dimensions16.54" x 19.41" x 18.74" (420 x 493 x 476 mm)
weight66.14 lb. (30 kg or less)
