Ricoh Aficio SP C231SF - Duplex Motor

Electrical Components
M018/M019 4-56 SM
4.11.11 DUPLEX MOTOR
1. Operation panel ( p.4-4)
2. Rear cover ( p.4-3)
3. Left cover ( p.4-5)
4. Disconnect the fusing connector [A]
5. Duplex timing belt [B]
6. Left bracket [C] (
x 4)
7. Duplex motor [D] (
x 2, x 1)
