Scanner
M018/M019 4-70 SM
4.13 SCANNER
4.13.1 SCANNER UNIT
1. Controller box cover ( p.4-43 "Controller Board")
2. Disconnect the flat cable [A].
3. Stand left cover [B] and right cover [C] (1 hook each)
4. Disconnect the scanner harness, power cord and ground cable (and the ADF harness
and power cord if the ADF is installed in the scanner unit) (
x 1).
5. Open the top cover of the machine.
