Ricoh Aficio SP C231SF - ID Chip Board

Electrical Components
M018/M019 4-50 SM
4.11.7 ID CHIP BOARD
1. Operation panel ( p.4-4)
2. Rear cover ( p.4-3)
3. Left cover ( p.4-5)
4. Controller bracket ( p.4-43 "Controller Board")
5. Disconnect the connector (CN305) on the EGB.
6. Interlock switch base ( p.4-47 "
