Paper Feed

M018/M019 4-36 SM

4.9 PAPER FEED

4.9.1 PAPER FEED CLUTCH

1. Rear cover ( p.4-3)

2. Left cover ( p.4-5)

3. Disconnect the fusing relay harness [A] (hook).

4. Paper feed clutch [B] (

x 1, x 1)
