Using the Fax Function from a Computer (LAN-Fax)
189
6
B Press the {Clear/Stop} key.
Configuring Transmission Settings
This section describes how to configure transmission settings in the LAN-Fax
driver's properties.
Properties are set separately for each application.
A On the [File] menu, click [Print…].
B Select the LAN-Fax driver as the printer, and then click a button such as [Ad-
vanced Options] or [Properties] to open the driver's properties.
LAN-Fax driver properties dialog box appears.
C Click the [Setup] tab.
D Configure settings as necessary, and then click [OK].
Reference
For details about settings, see p.190 “Settings you can configure in the
LAN-Fax driver's properties”.
BPC017S

Table of Contents

Other manuals for Ricoh Aficio SP C231SF

Preview: Service Manual
Service Manual292 pages
Preview: Information
Information36 pages
Preview: Specifications
Specifications4 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh Aficio SP C231SF and is the answer not in the manual?

Ricoh Aficio SP C231SF Specifications

Aficio SP C231SF

Engine Specifications IconEngine Specifications
print resolution600 x 600 dpi (Speed mode), 1200 x 600 dpi equivalent (Standard Mode), 2400 x 600 dpi equivalent (Fine Mode)
output speed21 pages-per-minute in B&W and Full-Color
first print speed14 seconds or less
warm-up time48 seconds or less
Power IconPower
power requirements120V, 60Hz
maximum power consumption1, 300W
energy saver mode20W
System Memory IconSystem Memory
memory (ram)128 MB RAM standard/maximum
standard interfacesUSB 2.0, 10/100Base-TX Ethernet
optional interfaceIEEE 802.11b/g Wireless
Weight and Dimensions IconWeight and Dimensions
dimensions16.54" x 19.41" x 18.74" (420 x 493 x 476 mm)
weight66.14 lb. (30 kg or less)

Aficio SP C232SF

Engine Specifications IconEngine Specifications
print resolution600 x 600 dpi (Speed mode), 1200 x 600 dpi equivalent (Standard Mode), 2400 x 600 dpi equivalent (Fine Mode)
output speed21 pages-per-minute in B&W and Full-Color
first print speed14 seconds or less
warm-up time48 seconds or less
Power IconPower
power requirements120V, 60Hz
maximum power consumption1, 300W
energy saver mode25W
System Memory IconSystem Memory
memory (ram)256 MB RAM standard/512 MB RAM maximum (shared)
standard interfacesUSB 2.0, 10/100Base-TX Ethernet
optional interfaceIEEE 802.11b/g Wireless
Weight and Dimensions IconWeight and Dimensions
dimensions16.54" x 19.41" x 18.74" (420 x 493 x 476 mm)
weight66.14 lb. (30 kg or less)
