Ricoh Aficio SP C231SF - Page 237

1.G1831630
ADF:ASS'Y
3.G1831741
COVER:FRONT:ADF
15.G1832553
COIL SPRING:GEAR:S
LIDE
16.G1832554
GEAR:SLIDE
18.G1832558
(x2)
PADDLE:ROLLER:EXI
T
19.G1832559
(x2)
DRIVEN ROLLER:EXI
T
7.G1831745
SIDE FENCE:LEFT
5.G1831743
BASE:SLIDER
8.G1831746
EXTENSION TRAY:A
DF
2.G1831740
FRAME:ADF
9.G1831747
PAPER STOPPER:AD
F
11.G1831822
ADF DECAL - PICK-U
P PAPER JAM
13.G1832551
COIL SPRING:ARM:SE
NSOR
4.G1831742
COVER:REAR:ADF
10.G1831775
HOOK:ADF
14.G1832552
(x4)
SHEET:ADF:KILO
21.G1832561
(x2)
COIL SPRING:EXIT
20.G1832560
SHAFT:DRIVEN ROLL
ER:EXIT
6.G1831744
SIDE FENCE:RIGHT
17.G1832555
CABLE:ADF
12.G1832550
ARM:SENSOR
U003_S001
ADF:ASS'Y
Copyright (c) 2006-2009 Ricoh Company, Ltd. 2009/12/29 Version 1.07
