Ricoh Aficio SP C320DN

5. Make sure that the markings on the fusing unit are aligned with the markings on the levers.
CBK171
If the markings are misaligned, align them by lowering the levers and once again pushing the fusing
unit fully in.
6. Slide the levers on the front cover outwards.
CBK131
7. Hold both ends of the paper transfer unit and lift it up.
CBK132
Place the paper transfer unit on a flat surface.
7. Maintaining the Printer
174
7
