Ricoh Aficio SP C320DN User Manual

2. Press [SSID], and then press [Enter].
3. Enter the characters, and then press [Accept].
You can switch among lower /upper cases and numeric characters by pressing [ABC/123].
The characters that can be used are ASCII 0 × 20-0 × 7e (32 bytes).
4. Press the [Menu] key to return to the initial screen.
5. Print a configuration page to confirm the settings.
• The SSID can also be set using a Web browser. For details, see Web Image Monitor Help.
• For details about printing the configuration page, see "Test Printing".
• p.43 "Test Printing"
Confirming Wireless Network Connectivity
After you have installed the Wireless LAN interface unit, use the following procedure to check for Wireless
LAN connectivity.
Make sure the LED on the Wireless LAN interface unit is lit.
CBK097
1
2
Wireless LAN Configuration
91
5

Ricoh Aficio SP C320DN Specifications

General

Print Technology	Laser
Duplex Printing	Yes
Processor	400 MHz
Supported Operating Systems	Windows, Mac OS, Linux
Resolution	1200 x 1200 dpi
Connectivity	USB 2.0, Ethernet
Memory	128 MB (expandable to 640 MB)
Dimensions	400 x 428 x 368 mm
Print Speed	Up to 26 ppm
Monthly Duty Cycle	Up to 50, 000 pages
