Ricoh Aficio SP C320DN

Installing the Wireless LAN Interface Board
• Before beginning work, ground yourself by touching something metal to discharge any static
electricity. Static electricity can damage the unit.
• Do not subject the unit to physical shocks.
1. Check the contents of the package.
BFL301S
2. Turn off the power, and then unplug the power cord.
3. Remove the cable cover.
CBK233
4. Remove the two screws and remove the cover of the slot in which the Wireless LAN interface
board is installed.
The removed cover is not used when the interface board is installed.
3. Installing Options
60
3
