Interior
This section introduces the names and functions of the parts inside of the printer.
4
2
1
2
3
5
6
CBK014
1. Print Cartridge
Loads from the printer rear, in the order of cyan (C), magenta (M), yellow (Y), and black (K).
If the following message appears on the control panel, replace the print cartridge:
"Replcmnt Requrd: Print Cart"
2. Fusing Unit
If the following message appears on the control panel, replace the fusing unit:
"Replacmnt Rqrd:Fusing Unit"
3. Transcription Roller
If the following message appears on the control panel, replace the transcription roller, which is included with the
fusing unit:
"Replacmnt Rqrd:Fusing Unit"
4. Paper Transfer Unit
Remove this unit when replacing the waste toner bottle, intermediate transfer unit.
5. Waste Toner Bottle
Collects toner that is wasted during printing.
If the message which prompts you to replace it appears on the display, replace the waste toner bottle.
"Waste Toner Bottle full"
6. Intermediate Transfer Unit
If the following message appears on the control panel, replace the intermediate transfer unit:
Interior
19
