Ricoh Aficio SP C320DN User Manual

5. Configuration
This chapter explains supported network connections, and settings for the IP addresses and the Wireless
LAN security.
Ethernet Configuration
Configure the following network settings according to the network interface you are using.
• Configure the printer for the network using the control panel.
• The following table shows the control panel settings and their default values. These items appear in
the [Network] under [Host Interface] menu.
Setting Name Default
Machine IPv4 Address
• Auto-Obtain (DHCP): On
• IPv4 Address: 11.22.33.44
• Subnet Mask: 0.0.0.0
• Gateway Address: 0.0.0.0
IPv6 Stateless Setting Active
IPsec Inactive
NW Frame Type Auto Select
Effective Protocol
• IPv4: Active
• IPv6: Inactive
• NetWare: Inactive
• SMB: Active
• AppleTalk: Inactive
Ethernet Speed Auto Select
IEEE802.1X Auth.(Ethernet) Inactive
Restr.IEEE802.1X Auth.Def. -
LAN Type Ethernet
79
5

Ricoh Aficio SP C320DN Specifications

General

Print Technology	Laser
Duplex Printing	Yes
Processor	400 MHz
Supported Operating Systems	Windows, Mac OS, Linux
Resolution	1200 x 1200 dpi
Connectivity	USB 2.0, Ethernet
Memory	128 MB (expandable to 640 MB)
Dimensions	400 x 428 x 368 mm
Print Speed	Up to 26 ppm
Monthly Duty Cycle	Up to 50, 000 pages
