Ricoh Aficio SP C320DN

3. Lift and pull Tray 1 carefully, and then pull it out with both hands.
CBK035
Place the tray on a flat surface. When there is paper in the tray, remove paper.
4. Wipe the friction pad with a damp cloth.
CBK181
5. Wipe the rubber part of the roller with a soft damp cloth. After that, wipe it with a dry cloth
to remove the water.
CBK182
Cleaning the Friction Pad and the Paper Feed Roller
183
7
