Ricoh Aficio SP C320DN

3. Remove the cable cover.
CBK233
4. Disconnect the cables from the Ethernet port and the USB port of the printer, and cover each
port with its protective cap.
CBK072
5. Remove the two screws and remove the cover of the slot in which the Gigabit Ethernet board
is installed.
The removed cover is not used when the interface unit is installed.
CBK073
3. Installing Options
58
3
