Ricoh Aficio SP C811DN Hardware Guide

4. Fully insert the interface unit.
ATU017S
Confirm that the interface unit is firmly connected to the controller board.
5. Tighten the two screws to secure the interface unit.
ATU018S
6. Attach the card to the card adapter. Attach them so that the label on both the card and
adapter is facing up.
ASZ032S
2. Installing Options
50
