Problem Cause Solution
[List / Test Print] is disabled. A mechanical error might
have occurred.
Contact your service representative.
Printing does not start when
using the extended wireless
LAN in Ad-hoc Mode.
The correct Communication
Mode is not set.
• Turn the main power switch off
and then back on again. For
details about how to turn on/off
the main power switch, see p.27
"Turning On/Off the Power".
• Change [Communication Mode]
in [System Settings] to [802.11
Ad-hoc Mode], and then select
[Off] for [Security Method]. For
details about Communication
Mode, see "Interface Settings",
Operating Instructions.
If printing does not start, contact your service representative.
When the Data In Indicator Does Not Light Up or Flash
When the Data In indicator does not light up or flash after starting a print job, data is not being sent to
the printer.
When the printer is connected to the computer using the interface cable
Check that the print port setting is correct. When connecting using a parallel interface, connect
using LPT1 or LPT2.
1. Open the printer properties dialog box, and then click the [Ports] tab.
For details about displaying the printer properties dialog box, see "Displaying the Printer
Driver Properties with Windows".
2. In the [Print to the following port(s)] list, check that the correct port is selected.
Network connection
For details about the network connection, contact your administrator.
3. Troubleshooting
108
