Open this cover when replacing the black drum unit/color drum units or transfer unit.
4. Black drum unit / Color drum units
From the left, the drum units are installed in the order of black (K), yellow (Y), magenta (M), and cyan (C).
Replace the relevant black drum unit/color drum units when the following message appears:
• "Replacement of Color Photoconductor Unit is now necessary. Replace Color Photoconductor Unit."
• "Replacement of Black Photoconductor Unit is now necessary. Replace Black Photoconductor Unit."
5. Transfer unit
Replace the transfer unit when the following message appears:
• "Replacement of Transfer Unit is now necessary. Replace Transfer Unit."
6. Toner
From the left, the toner is installed in the order of black (K), yellow (Y), magenta (M), and cyan (C).
Replace the relevant toner when the following message appears:
• " No toner. Replace Toner Cartridge."
Guide to the Names and Functions of the Printer's Control Panel
This illustration shows the control panel of the printer with options fully installed.
Guide to Names and Functions of Components
