Message Cause Solution
"Hardware Problem: Parallel
I/F"
An error has occurred in the
IEEE 1284 interface board.
Turn the main power switch off
and then confirm the IEEE 1284
interface board is inserted
correctly. For details about
installing the board, see
"Installing the Interface Units",
Operating Instructions.
If the message appears again,
contact your service
representative.
"Hardware Problem: USB" An error has occurred in the
USB interface.
Turn the main power switch off and
then back on again. If the message
appears again, contact your service
representative.
"Hardware Problem:
Wireless Card"
The wireless LAN board can
be accessed, but an error
was detected.
Turn off the main power switch,
and then confirm the wireless LAN
board is inserted correctly. For
details about installing the board,
see "Installing the Interface Units",
Operating Instructions.
If the message appears again,
contact your service
representative.
"Out of paper in n. Load
paper of the following size
and type. To cancel the
current job, press [Job
Reset]."
("n" is a figure.)
The printer driver settings are
incorrect or the tray does not
contain paper of the size
selected in the printer driver.
Check that the printer driver settings
are correct, and then load paper of the
size selected in the printer driver into
the input tray. For details about how to
change the paper size, see p.49
"Loading Paper".
When Messages Are Displayed
93

Table of Contents

Other manuals for Ricoh Aficio SP C830DN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh Aficio SP C830DN and is the answer not in the manual?

Ricoh Aficio SP C830DN Specifications

SP C830DN

Power IconPower
power requirements120 – 127V, 60Hz
power consumption1.1 W (Sleep Mode)
TEC2.033 kWH/week
Performance IconPerformance
printing speed45-ppm B&W and full-color
warm-up time29 seconds or less
first print speedB&W: 3.7 seconds or less; Full Color: 5.7 seconds or less
Print Specifications IconPrint Specifications
print resolution300 x 300 dpi, 600 x 600 dpi, 1200 x 1200 dpi
standard paper supply1, 200 sheets total capacity
maximum paper supply4, 400 sheets
Weight and Dimensions IconWeight and Dimensions
dimensions26.4" x 26.9" x 25.2" (670 x 684 x 640 mm)
weightLess than 213 lb. (97 kg)

SP C831DN

Power IconPower
power requirements120 – 127V, 60Hz
power consumption1.1 W (Sleep Mode)
TEC2.638 kWH/week
Performance IconPerformance
printing speed55-ppm B&W and full-color
warm-up time25 seconds or less
first print speedB&W: 3.4 seconds or less; Full Color: 5.1 seconds or less
Print Specifications IconPrint Specifications
print resolution300 x 300 dpi, 600 x 600 dpi, 1200 x 1200 dpi
standard paper supply1, 200 sheets total capacity
maximum paper supply4, 400 sheets
Weight and Dimensions IconWeight and Dimensions
dimensions26.4" x 26.9" x 25.2" (670 x 684 x 640 mm)
weightLess than 213 lb. (97 kg)
