Ricoh GR II User Manual

6
Appendices
173
Camera Care and Storage
Caring for the Camera
• Image quality can be affected by fingerprints and other foreign matter on the
lens. Avoid touching the lens with your fingers.
• Remove dust or lint on the lens with a commercially available blower, or gently
clean the lens with a soft, dry cloth.
• Clean the camera thoroughly after using it at the beach or handling chemicals.
• In the unlikely event of malfunction, consult your nearest repair center.
• The camera contains high-voltage circuits. Do not disassemble.
• Do not expose the camera to volatile substances such as thinner, benzine, or
pesticides. Failure to observe this precaution could result in damage to the
camera or its coatings.
• The picture display is easily scratched, avoid touching it with hard objects.
• Clean the picture display by wiping it with a soft cloth dampened with a small
amount of any monitor cleaner that does not contain organic solvents.
Storage
• Do not store the camera where it will be exposed to:
- extreme heat or humidity
- large changes in temperature or humidity
- dust, dirt, sand, severe vibration
- prolonged contact with chemicals including mothballs and other insect re-
pellent, or with vinyl or rubber products
- strong magnetic fields (for example, in the vicinity of a monitor, transformer,
or magnet)
Otherwise your camera may be damaged.
• Remove the battery if the product is left unused for a long period of time.
Before Cleaning
• Be sure to turn the camera off.
• Remove the battery.

Ricoh GR II Specifications

General

Megapixel	16.2 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	No
Total megapixels	16.9 MP
Image sensor size	- \
Image formats supported	RAW, JPG
Maximum image resolution	4928 x 3264 pixels
Still image resolution(s)	[3:2]4928×3264 (L), 3936×2608 (M), 2912×1936 (S), 1280×864(XS) [4:3]4352×3264 (L), 3488×2608 (M), 2592×1936(S), 1152×864(XS) [1:1]3264×3264(L), 2608×2608(M), 1936×1936(S), 864×864 (XS)
Video recording	Yes
Video resolutions	1920 x 1080, 1280 x 720, 640 x 480 pixels
Video formats supported	H.264, MPEG4, AVC
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 25600
Light exposure modes	Aperture priority AE, Manual, Auto, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 2EV (1/3EV step)
Maximum aperture number	16
Minimum aperture number	2.8
Lens structure (elements/groups)	7/5
Maximum focal length (35mm film equiv)	28 mm
Minimum focal length (35mm film equiv)	18.3 mm
Focus	TTL
Auto focusing (AF) modes	Multi Point Auto Focus, Spot Auto Focus, Continuous Auto Focus
Display diagonal	3 \
Vari-angle LCD display	-
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	300 s
Flash modes	Auto, Manual, Slow synchronization, Flash on
Flash range (tele)	0.2 - 3 m
Scene modes	Beach
Photo effects	Black&White
White balance	Incandescent, Auto, Shade, Cloudy, Daylight
Self-timer delay	2 s
Camera file system	Exif 2.3
Memory slots	1
Internal memory	54 MB
Compatible memory cards	SD, SDHC, SDXC
Product color	Black
Wi-Fi standards	802.11g, 802.11b, Wi-Fi 4 (802.11n)
USB version	2.0
Power source type	Battery
Battery type	DB-65
Battery life (CIPA standard)	290 shots
Cables included	USB

Weight and Dimensions

Depth	34.7 mm
Width	117 mm
Height	63 mm
Weight	221 g
Weight (including battery)	251 g
