Item Specifications
Stack capacity after saddle
stitching (80 g/m
2
, 20 lb.
Bond)
• 2-5 sheets: approx. 20 sets
• 6-10 sheets: approx. 10 sets
• 11-15 sheets: approx. 7 sets
(Stack capacity depends on the paper type and use conditions.)
Saddle stitch position Center 2 positions
Types of folds Half Fold
Half fold paper size A3 , A4 , B4 JIS , B5 JIS , 11 × 17 , 8
1
/
2
× 14 , 8
1
/
2
× 11
, 12 × 18 , 8
1
/
2
× 13
2
/
5
Half fold paper weight 52-105 g/m
2
(14-28 lb. Bond)
Half fold paper type Plain 1, Plain 2, Recycled Paper, Middle Thick, Thin Paper, Color
Paper
Power requirements Power is supplied from the main unit.
Maximum power
consumption
36 W or less
Dimensions
(W × D × H)
• 575 × 620 × 960 mm (22.6 × 24.5 × 37.8 inches) (Tray is
folded.)
• 658 × 620 × 960 mm (25.9 × 24.5 × 37.8 inches) (Tray is
extended.)
(the height to reach the top board)
Weight Approx. 44 kg (97.1 lb.)
• The Half Fold function can fold one sheet at a time.
10. Specifications for The Machine
342
