Ricoh P C300W Field Service Manual

4.Replacement and Adjustment
108
2. Turn on the machine.
If the machine issues a "Cover Open" error, ignore it and to the next step below.
3. Enter the SP mode.
4. Execute [Init Engine EEPROM].
• Printer model: Engine Maintenance > Destination
• MF model: Engine Service Setting > Destination
EEPROM Initialization starts.
5. Exit the SP mode.
6. Enter the Special Maintenance Menu for setting a machine serial number.
For further information, contact your supervisor in your branch office.
7. Input the machine serial number.
8. Exit the serial number input display, and then enter the SP mode again.
9. Select a destination.
• Printer model: Engine Maintenance > Destination
• MF model: Engine Service Setting > Destination
10. Select a model.
• Printer model: Engine Maintenance > Model
• MF model: Engine Service Setting > Model
11. Enter a Plug & Play name.
• Printer model: Engine Maintenance > PnP Name
• MF model: Engine Service Setting > PnP Name
Enter the appropriate Plug & Play name according to the model:
• P C300W: 0x00
• P C301W: 0x03
• M C250FWB: 0x08
• M C250FW: 0x0B
12. Write the LD parameters of the laser optics housing unit to the new EEPROM.
• Printer model: Engine Maintenance > Init. LSU Data
• MF model: Engine Service Setting > Init. LSU Data
13. Turn off the machine.
14. With the front cover still open, turn on the machine.
15. Enter the SP mode again.
16. Close the front cover.
17. Execute [Trans. Belt Adjust] to adjust the image transfer belt unit.
• Printer model: Engine Maintenance > Trans. Belt Adj.
• MF model: Engine Service Setting > Trans. Belt Adjust
18. Select [Fuser SC Detect], and then select "ON" or "OFF" for consecutive fusing jam detection.

Ricoh P C300W Specifications

General

Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	9.4 s
Time to first page (color, normal)	9.8 s
Print speed (black, normal quality, A4/US Letter)	25 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	30000 pages per month
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PostScript 3
Product color	Black, White
Market positioning	Home & office
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	1300 W
Energy Star Typical Electricity Consumption (TEC)	0.3 kWh/week
Duplex media weight	60 - 90 g/m²
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	60 - 163 g/m²
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	751 sheets
Auto document feeder (ADF) input capacity	1 sheets
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
USB 2.0 ports quantity	1
Built-in processor	-
Sound pressure level (printing)	- dB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Cables included	AC
Included cartridge capacity (black)	1000 pages

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	334 mm
