Ricoh P C300W Field Service Manual

5.System Maintenance
131
Menu
Description
This calibrates the motor speed to match
the length of the new transfer belt.
Fuser SC
Detect
Fus. Jam Dete.
Determines whether or not the SC code
is issued after three successive jams in
the fusing unit.
[0 (OFF) or 1(ON)]
SC Number
Displays the SC number occurred.
Temp.occurred
Heat Center
Displays the temperature (°C) at the
fusing thermopile when the fusing related
SC occurred.
Heat NC
Displays the temperature (°C) at the
fusing NC sensor when fusing related SC
occurred.
Press Center
Displays the temperature (°C) at the
pressure roller thermistor (center) when
fusing related SC occurred.
Press Left
Displays the temperature (°C) at the
pressure roller thermistor (end) when
fusing related SC occurred.
Press Right
(Reserved)
Temp.bf 1Cyc
Heat Center
Displays the temperature (°C) of each
sensor at the occurrence of the 1st fusing
SC code before the current SC code.
Heat NC
Press Center
Press Left
Press Right
Temp.bf 2Cyc
Heat Center
Displays the temperature (°C) of each
sensor at the occurrence of the 2nd
fusing SC code before the current SC
code.
Heat NC
Press Center
Press Left
Press Right
Temp.bf 3Cyc
Heat Center
Displays the temperature (°C) of each
sensor at the occurrence of the 3rd
fusing SC code before the current SC
code.
Heat NC
Press Center
Press Left
Press Right
Fuser SC
Reset
Fusing SC Reset
Resets the fusing related SC.
Hard High Temp. Dete.
Resets the fusing related SC when high-

Ricoh P C300W Specifications

General

Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	9.4 s
Time to first page (color, normal)	9.8 s
Print speed (black, normal quality, A4/US Letter)	25 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	30000 pages per month
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PostScript 3
Product color	Black, White
Market positioning	Home & office
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	1300 W
Energy Star Typical Electricity Consumption (TEC)	0.3 kWh/week
Duplex media weight	60 - 90 g/m²
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	60 - 163 g/m²
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	751 sheets
Auto document feeder (ADF) input capacity	1 sheets
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
USB 2.0 ports quantity	1
Built-in processor	-
Sound pressure level (printing)	- dB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Cables included	AC
Included cartridge capacity (black)	1000 pages

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	334 mm
