6.Troubleshooting
227
Transport path
Length (mm)
Note
Paper feed roller - Friction pad nip
9.5
Registration sensor ON - Registration sensor OFF
8.2
Registration sensor ON - Registration roller
14.3
Registration roller - Paper transfer roller
38.1
Paper transfer roller - Fusing entrance sensor ON
60.7
Fusing entrance sensor ON - Fusing entrance sensor OFF
3.0
Paper transfer roller - Fusing sleeve belt
97.3
Fusing sleeve belt - Paper exit sensor ON
59.2
Paper exit sensor ON - Paper exit sensor OFF
18.4
Paper exit sensor ON - Paper exit roller
47.0
Paper exit roller - Duplex roller
200.0
Duplex roller - Registration sensor ON
174.6
Registration sensor ON - Registration roller
17.0
Duplex feed
Exposure - Image transfer roller (Bk)
37.2
Image transfer roller (Bk) - TM/P sensor
219.61
TM/P sensor - Paper transfer roller
330.08
Image transfer roller (Bk) - Paper transfer roller
549.69
Paper Feed Unit TK1220
Transport path
Length (mm)
Note
Paper feed roller - Paper transport roller
47.1
Paper transport sensor - Paper transport roller
5.3
Paper transport roller - Registration sensor ON
86.0
Registration sensor ON - Registration roller
17.0
Paper transport roller - Duplex feed junction
61.0
