4.Replacement and Adjustment
66
2. Remove the operation panel. (Operation Panel)
3. Remove the right cover. (Right Cover)
4. Remove the motor bracket [A]. ( × 2)
5. Release the wire [B] and remove the ITB contact motor assembly [C]. ( × 1, × 1)
6. Remove the ITB contact motor (M6) [D]. ( × 2)
To Next Page
