Ricoh SP 4510dn User Manual

29. Click [Next].
30. In [Name], enter an IP Filter action name, and then click [Next].
31. Select "Negotiate security", and then click [Next].
32. Select "Allow unsecured communication if a secure connection connect be established.",
and then [Next].
33. Select "Custom" and click [Settings].
34. In "Integrity algorithm", select the authentication algorithm that was specified on the
printer in "Encryption Key Auto Exchange Settings Phase 2".
35. In "Encryption algorithm", select the encryption algorithm that specified on the printer in
"Encryption Key Auto Exchange Settings Phase 2".
36. In Session key settings, select "Generate a new key every", and enter the validity period
(in seconds) that was specified on the printer in "Encryption Key Auto Exchange Settings
Phase 2".
37. Click [OK].
38. Click [Next].
39. Click [Finish].
40. Select the filter action that was just created, and then click [Next].
If you specify the "Authentication and High Level Encryption" security level in "Encryption Key Auto
Exchange Settings", also select the "Use session key perfect forward secrecy (PFS)" check box in
the filter action properties screen. If using PFS in Windows, the PFS group number used in phase 2
is automatically negotiated in phase 1 from the Diffie-Hellman group number (set in Step 11).
Consequently, if you change the security level specified automatic settings on the printer and "User
Setting" appears, you must set the same the group number for "Phase 1 Diffie-Hellman Group" and
"Phase 2 PFS" on the printer to establish IPsec transmission.
41. Select the authentication method, and then click [Next]. For Windows XP, go to Step 42.
If you select "Certificate" for authentication method in "Encryption Key Auto Exchange Settings" on
the printer, specify the device certificate. If you select "PSK", enter the same PSK text specified on
the printer with the pre-shared key.
42. Click [Finish].
43. Click [OK].
The new IP security policy (IPsec settings) is specified.
44. Select the security policy that was just created, right-click,, and then click [Assign].
IPsec settings on the computer are enabled.
• To disable the computer's IPsec settings, select the security policy, right click, and then click [Un-
assign].
5. Enhanced Network Security
138

Ricoh SP 4510dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	5 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Printing colors	Black
Maximum duty cycle	150000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6
Total input capacity	600 sheets
Maximum input capacity	1600 sheets
Paper tray media types	Plain paper, Pre-Printed, Recycled paper, Thick paper, Thin paper
Paper tray media weight	52 - 162 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Letterhead
Maximum ISO A-series paper size	A4
Wi-Fi	-
Supported network protocols (IPv4)	TCP/IP
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Storage media	HDD
Internal memory	512 MB
Maximum internal memory	1536 MB
Internal storage capacity	320 GB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1110 W
Power consumption (printing)	- W
Power consumption (PowerSave)	1 W
Product color	Grey, White
Cables included	AC

Weight and Dimensions

Depth	392 mm
Width	370 mm
Height	306 mm
Weight	14000 g
