Ricoh SP 4510dn User Manual

Offset Range Meaning Error Code
6 RESOURCE ID FORMAT (RIDF) X'028F..
01'
X'03' IBM Registered Global Resource ID parts
X'06' MVS host unalterable remote font environment
X'07' Coded font
X'09' Object-OID
X'0A' Data-object font
7-8 FONT INLINE SEQUENCE X'028F..
01'
X'0000' 0 degrees
X'2D00' 90 degrees
X'5A00' 180 degrees
X'8700' 270 degrees
That the Font Inline Sequence is ignored for RT=X'06' and
X'07'.
For outline fonts with RT=X'10', FIS is used to select the
character metrics for a specific writing mode.
9-10 X'0000' Reserved
11 RESOURCE CLASS FLAGS
Bit 0 0/1 Public/Private (Resource Capture)
Bit 1 0 Retired
Bit 2 0/1 Ignored (Reset)
Bit 3 0/1 AR NACK Enabled
Bit 4 0/1 Outline Font Substitution
Bits 5-7 0 Reserved
Bytes
12-n
RESOURCE ID and triplets X'028F..
01'
Activate Resource
15

Ricoh SP 4510dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	5 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Printing colors	Black
Maximum duty cycle	150000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6
Total input capacity	600 sheets
Maximum input capacity	1600 sheets
Paper tray media types	Plain paper, Pre-Printed, Recycled paper, Thick paper, Thin paper
Paper tray media weight	52 - 162 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Letterhead
Maximum ISO A-series paper size	A4
Wi-Fi	-
Supported network protocols (IPv4)	TCP/IP
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Storage media	HDD
Internal memory	512 MB
Maximum internal memory	1536 MB
Internal storage capacity	320 GB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1110 W
Power consumption (printing)	- W
Power consumption (PowerSave)	1 W
Product color	Grey, White
Cables included	AC

Weight and Dimensions

Depth	392 mm
Width	370 mm
Height	306 mm
Weight	14000 g
