Ricoh SP 5300DN User Manual

3. Loosen the two screws and remove the slot cover.
DPL009
The removed cover will not be reused.
4. Fully insert the interface board.
DPL010
Check that the interface board is firmly connected to the controller board.
5. Tighten the two screws to secure the interface board.
DPL011
6. Plug in the power cord, and then turn on the printer.
7. Print the configuration page to confirm that the board was attached correctly.
Installing Options
19

Ricoh SP 5300DN Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Maximum Memory	2 GB
Connectivity	USB 2.0, Ethernet
Processor Speed	1.46 GHz
Maximum Paper Size	A4
Maximum Paper Capacity	2, 600 sheets
Duplex Printing	Yes
Media Sizes Supported	A4, A5, A6, B5, Legal, Letter
PDL	PCL5e, PCL6, PostScript 3
Operating System Compatibility	Windows, Mac, Linux
