2.Replacement and Adjustment
52
2. Replacement and Adjustment
Covers
Rear Upper Cover, Rear Lower Cover
1. Remove the rear upper cover [A].
2. Remove the rear lower cover [A].
Upper Cover
1. Remove the rear upper cover. (Rear Upper Cover, Rear Lower Cover)
