Ricoh SR5090 - Shift Tray (Upper Tray); End Fence

2.Replacement and Adjustment
57
2. Remove the proof tray [A].
Shift Tray (Upper Tray)
1. Remove the shift tray [A].
End Fence
1. Remove the rear lower cover (Finisher SR5090 only). (Rear Upper Cover, Rear Lower Cover)
2. Remove the paper guide cover. (Paper Guide Cover)
3. Remove the shift tray. (Shift Tray (Upper Tray))
