Ricoh SR5090 - Press Fold Motor

2.Replacement and Adjustment
81
4. Remove the screws securing the finisher and saddle stitch unit.
5. Lift up to remove the saddle stitch unit [A].
Press Fold Motor
1. Remove the saddle stitch unit (Saddle Stitch Unit).
