1.Detailed Descriptions
6
with the paper exit roller [E], thus allowing a larger amount to be retracted.
New Sensors
Two sensors [A] (the front and rear Sub Height Sensors) were added to detect stapled sheets.
When sheets stapled at one point (corner stapling) are stacked, the height of the stapled corner is
higher and hits the paper guide, edge guide, or the next stapled booklet. When one of the sensors
detects paper, the machine determines that the height limit has been reached and stops printing.
Easier Replacement of Staple Cartridge
The exterior of the stapler unit has been changed from a bracket to a resin cover.
The handle [A] is joined to the cover, and there is a decal [B] for checking operation.
