Ricoh SR5090 - Boards; Controller Board (PCB1)

2.Replacement and Adjustment
61
Boards
Controller Board (PCB1)
1. Remove the following covers.
• Rear upper cover (Rear Upper Cover, Rear Lower Cover)
• Rear lower cover (Rear Upper Cover, Rear Lower Cover)
2. Remove the Controller Board [A].
Booklet Finisher SR5100
Finisher SR5090
