2.Replace
ment and
Adju
stment
91
Paper Guide Motor
The paper gu
ide motor is
at [A].
1.
Remove
the paper guid
e unit. (
Paper
Guide Unit
)
2.
Remove
sensor brac
ket (
x1).
3.
Unfasten t
he motor
, and d
i
sconne
ct the belt (
x2,
x1).
