Ridder LogicLink RLL400 User Manual

7.2 Check: Control direcon of the Automac Control (ACS)
1. Set the switch of the manual control (MC) (if connected) to “Automac mode”.
2. Use the automac control-system (ACS). Let the motor gearbox turn in a direcon that can cause
no damage to the operated system.
3. Make sure that the direcon of the automac control (ACS) agrees with the necessary moving
direcon (of the operated system).
CORRECT - Go to step 6.
NOT CORRECT - De-energize the system. Go to step 4.
4. Interchange the connecons 1 and 3 of connector X6.
5. Energize the system. Go to step 1.
6. The check procedure of the direcon-of-rotaon of the automac control is completed.
Control board A2
A1
24 V (AC/DC)
Ridder Drive Systems B.V.
T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com
25
