Rigaku Progeny - Instrument Controls and Navigation

Introduction 9
1006232_RevD
Figure 2: Front View
Figure 3: Battery-door View
Carrying Your Instrument
When moving your Progeny Analyzer from one work site to another, RAD recommends using the
carrying case and including the following items:
 Charger
 Cables
 Battery
 Instrument
 Any RAD instrument accessories
Close both latches to secure the case before lifting it.
Important:
When packed with your instrument and all its accessories, the case weighs as much as 20 lbs.
(9.1 kg). Please consider this when lifting your instrument.
Camera
Heat sink
Laser aperture
Battery-door assembly
