Rigol DHO804 User Manual

Figure 18.2 MarkTable Display ..........................................................................................194
Figure 18.3 Navigation Menu ........................................................................................... 195
Figure 18.4 Simplified Navigation Menu ...................................................................... 195
Figure 18.5 "Search Event" Navigation Setting Menu ..............................................196
Figure 18.6 "Frame Segment" Navigation Setting Menu ........................................196
Figure 19.1 Display Setting Menu ................................................................................... 198
Figure 20.1 Image Saving Setting Menu .......................................................................202
Figure 20.2 Waveform Saving Setting Menu ...............................................................204
Figure 20.3 Setup Saving Setting Menu ........................................................................205
Figure 20.4 Load Setting Menu ........................................................................................210
Figure 20.5 Upgrade Menu ................................................................................................211
Figure 20.6 Disk Management Interface .......................................................................212
Figure 21.1 Self-calibration Menu ................................................................................... 220
Figure 21.2 Quick Menu ......................................................................................................221
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO800 User Guide
XI

Rigol DHO804 Specifications

General

Bandwidth	70 MHz
Channels	4
Waveform Capture Rate	1, 000, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	12 bits
Interfaces	USB, LAN, HDMI
Input Impedance	1 MΩ ± 1%
Max Input Voltage	300 Vrms CAT I
Trigger Types	Edge, Pulse, Slope, Video, Pattern, Duration, Timeout, Runt, Window, Delay, Setup/Hold, Nth Edge, Logic
Protocol Decoding	I2C, SPI, UART, CAN, LIN, FlexRay, I2S
USB Ports	USB Host, USB Device
LAN Port	1
