Rigol DHO804 User Manual

List of Tables
Table 4.1 Power Adaptor Specifications ...........................................................................
12
Table 5.1 Probe Ratio ..............................................................................................................43
Table 8.1 Video Standard ...................................................................................................... 74
Table 9.1 Window Function ................................................................................................116
Table 9.2 Logic Operation .................................................................................................. 119
Table 15.1 Bus Setting ..........................................................................................................170
Table 20.1 BIN File Format ................................................................................................. 206
Table 20.2 File Header ..........................................................................................................207
Table 20.3 Waveform Header ............................................................................................207
Table 20.4 Waveform Data Header ................................................................................. 209
Table 24.2 Factory Settings ................................................................................................229
DHO800 User Guide
XII
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

Rigol DHO804 Specifications

General

Bandwidth	70 MHz
Channels	4
Waveform Capture Rate	1, 000, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	12 bits
Interfaces	USB, LAN, HDMI
Input Impedance	1 MΩ ± 1%
Max Input Voltage	300 Vrms CAT I
Trigger Types	Edge, Pulse, Slope, Video, Pattern, Duration, Timeout, Runt, Window, Delay, Setup/Hold, Nth Edge, Logic
Protocol Decoding	I2C, SPI, UART, CAN, LIN, FlexRay, I2S
USB Ports	USB Host, USB Device
LAN Port	1
