Rigol DHO804 User Manual

Parameter Factory Settings
Operation OFF
Source A CH1
Waveform Size Medium
Offset 0 div
Sensitivity 300 mdiv
Thre.CH1 0 V
Thre.CH2 0 V
Thre.CH3 0 V
Thre.CH4 0 V
Intg
Operation OFF
Source CH1
Scale 500 mV*s
Offset 0 V*s
Offset 0 V
Diff
Operation OFF
Source CH1
Scale 500 mV/s
Offset 0 V/s
Smooth 5
Sqrt
Operation OFF
Source CH1
Scale 500 mU
Offset 0 U
Lg
Operation OFF
Source CH1
Scale 500 mU
Offset 0 U
Ln
Operation OFF
Source CH1
Scale 500 mU
Offset 0 U
Exp
Operation OFF
Source CH1
Scale 500 mU
Offset 0 U
Appendix
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO800 User Guide
235

Rigol DHO804 Specifications

General

Bandwidth	70 MHz
Channels	4
Waveform Capture Rate	1, 000, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	12 bits
Interfaces	USB, LAN, HDMI
Input Impedance	1 MΩ ± 1%
Max Input Voltage	300 Vrms CAT I
Trigger Types	Edge, Pulse, Slope, Video, Pattern, Duration, Timeout, Runt, Window, Delay, Setup/Hold, Nth Edge, Logic
Protocol Decoding	I2C, SPI, UART, CAN, LIN, FlexRay, I2S
USB Ports	USB Host, USB Device
LAN Port	1
