Rigol DHO804 User Manual

Parameter Factory Settings
Abs
Operation OFF
Source CH1
Scale 500 mV
Offset 0 V
Low Pass
Operation OFF
Source CH1
Scale 500 mV
Offset 0 V
ωc 20 MHz
High Pass
Operation OFF
Source CH1
Scale 500 mV
Offset 0 V
ωc 20 MHz
Band Pass
Operation OFF
Source CH1
Scale 500 mV
Offset 0 V
ωc1 20 MHz
ωc2 40 MHz
Band Stop
Operation OFF
Source CH1
Scale 500 mV
Offset 0 V
ωc1 20 MHz
ωc2 40 MHz
AX+B
Operation OFF
Source CH1
Scale 500 mV
Offset 0 V
A 1
B 0
Ref
Current Ref1
Source CH1
Appendix
DHO800 User Guide
236
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

Rigol DHO804 Specifications

General

Bandwidth	70 MHz
Channels	4
Waveform Capture Rate	1, 000, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	12 bits
Interfaces	USB, LAN, HDMI
Input Impedance	1 MΩ ± 1%
Max Input Voltage	300 Vrms CAT I
Trigger Types	Edge, Pulse, Slope, Video, Pattern, Duration, Timeout, Runt, Window, Delay, Setup/Hold, Nth Edge, Logic
Protocol Decoding	I2C, SPI, UART, CAN, LIN, FlexRay, I2S
USB Ports	USB Host, USB Device
LAN Port	1
