User Manual for DM3000 Series
Chapter 3 : Application & Examples
Example 1: Reading Statistic Functions
How to obtain the statistic of the maximum value read in the measurement.
When the total function is running, the first reading is taken the maximum value
shown on the display. When continuously measures many readings, the multimeters
renews the maximum value unceasingly.
Do these steps as follows:
1. Connect test leads as Chapter 1 introduced. Now we want to measure an AC
Voltage. Connect test leads as shown:
Figure 3-1
2. Press button, select AC Voltage measurement function. Choose a correct
range.
3. Set the Statistic measurement function parameters.
(1). Press Æ Stats Æ Max , choose maximum value measurement.
(2). Press
, save all changes, back to a higher level menu.
AC Voltage
