Rigol DM3000 Series User Manual

RIGOL
1-4 © Copyright RIGOL Technologies, Inc. 2007.
User Manual for DM3000 Series
The Front/Rear Panel and User Interface
After you get a new DM3000 Digital Multimeter, first, you need to clear how to
operate the front panel of the DM3000 correctly. This chapter will make a brief
introduction and description for the operation and functions of the Front Panel.
The front panel of the DM3000 is very simple and clear for users operation. The front
panel include direction buttons and functions buttons.
Figure 1-4
USB Host
District Purple:
Measurement Function
Ke
y
s
Menu Operation
Keys
Blue Direction:
Function Selective
Keys
Current Input Terminal
Direction Keys
LCD Display
District Yellow:
Trigger Control Keys
On/Off Switch
