User Manual for DM3000 Series
Reading Hold
The reading hold mode allows you to capture and hold a stable reading on the front
panel display. This is useful in situations when you want to take a reading, remove
the test probes, and have the reading remain on the display. When a stable reading
is detected the reading will hold on the display. Hold scope include 0.01%, 0.1%, 1%,
and 10%.
Press Æ Auto Æ Hold , enter the menu shown below:
Figure 2-20
Table 2-18 Reading Hold Function Menu Explanation
Function
Menu
Explanation
On/Off
Turn on/off the reading hold function.
0.01％ Set the hold scope is 0.01％.
0.1％ Set the hold scope is 0.1％.
1%
Set the hold scope is 1％.
10%
Set the hold scope is 10％.
Save all changes, back to a higher level menu.
