Rigol DM3000 Series User Manual

RIGOL
2-20 © Copyright RIGOL Technologies, Inc. 2007.
User Manual for DM3000 Series
Auto Triggering
Auto triggering takes continuous readings at the fastest rate possible for the
specified measurement configuration (function, range, resolution, and so forth).
Auto trigger is a default trigger mode when the multimeter power-on.
Press Æ Auto , enter the menu shown below:
Figure 2-19
Table 2-16 Auto Trigger Function Menu Explanation
Interval time:
You can manually specify a delay between the trigger signal and the first sample that
follows. This may be useful in applications where you want to allow the input signal
to settle before taking a reading, or for pacing a burst of readings.
• The trigger delay may be set from 0 to 3600 seconds.
• The continuity and diode test functions ignore the trigger delay setment.
• If a trigger delay is not manually set, the default trigger delay is automatically set.
• If you manually specify a trigger delay, that delay is used for all measurement
functions (except continuity and diode test).
Function
Menu
Setting
Explanation
Interval
Set interval time in 0~3600S.
Hold
Save all changes, back to a higher level menu.
