User Manual for DM3000 Series
6-6
DM3000 Series Digital Multimeters
Range:
Or
Performance Parameters
Resolution,
Or
AC Voltage Frequency:
Accuracy:
1 Year
±(% of reading +
% of range)
Input Current,
Or Current Source:
Diodes test 2V Range, 1mA test current, 2.4V Max forward voltage drop
Arbitrary Sensor
Support multiple ANSI standard thermocouple and the sensor
withvoltage, current, and resistance output.
Frequency and Period 3Hz(0.333s)-300k Hz(3.33μs)
Math Null, Max/Min/Avg, dBm, dB, and Limit Test.
Data Acquisition Data Record, Inspection, Programmable Auto Measure.
Other Functions
Auto Reading Hold, Ratio Test, Built-in 10 setup storage, 1M points of
memory depth.
High-speed Data Logger 50K/s (High-speed Data Logger)
Measurement Precision 2,400,000 Count, >6 1/2
USB I/O Interface USB Hostto support USB disk and USB printer; USB Device
Other I/O Interfaces RS232, GPIB(Optional), LAN(Option)
Display
256×64 pixels LCD to support multi-display, menu, multi-language help
and waveform display.
Data Acquisition
and Virtual
Support Microsoft® Windows 98/Me, Windows 2000/XP.
Max Input
1,000VDC, 750VRMS AC, DC&AC max external current 10A, internal
current 2A double fuses
Shock and Vibration MIL-T-28800, Type III, Class 5
Power 115/230V, 45-65Hz, 20W Max
Weight 2.5kg
Size 107.0mmH×231.6mmW×290.5mmD
