RIGOL
1-8 © Copyright RIGOL Technologies, Inc. 2007.
User Manual for DM3000 Series
required, direct implementation of the next step.
(To know the specific setting methods of the Null value setting, please refer to
Chapter 2 “To Set Up Measurement Parameters”, Null computing)
6. Lead test leads into circuit, starts to measurement.
Figure 1-8
DC Voltage measurement instruction chart
7. Measurement history data processing
Press History , enter the menu shown below:
Figure 1-9
To check or save the data that has measured by current measurement function,
you can use the history function. In this function you can get the “Info” (information),
“List” and “Graph” of this measurement. Also, you can save this information data
with press Save softkey.
Note
If the users can not predict the scope of the measurement, please choose Auto
range to obtain more accurate measurement data.
DC Voltage
To Next Page
