User Manual for DM3000 Series
(To know the specific setting methods of the Null value setting, please refer to
Chapter 2 “To Set Up Measurement Parameters”, Null computing)
6. Lead test leads into circuit, starts to measurement.
Figure 1-11
AC Voltage measurement instruction chart
7. Measurement history data processing
Press History , enter the menu shown below:
Figure 1-12
To check or save the data that has measured by current measurement function,
you can use the history function. In this function you can get the “Info” (information),
“List” and “Graph” of this measurement. Also, you can save this information data
with press Save softkey.
AC Voltage
