User Manual for DM3000 Series
user demand. If user does not implement Null computing, this parameter is not
required, direct implementation of the next step.
(To know the specific setting methods of the Null value setting, please refer to
Chapter 2 “To Set Up Measurement Parameters”, Null computing)
6. Lead test leads into circuit, starts to measurement.
Figure 1-17
AC Current measurement instruction chart
7. Measurement history data processing
Press History , enter the menu shown below:
Figure 1-18
The history data
To check or save the data that has measured by current measurement function, you
can use the history function. In this function you can get the “Info” (information),
“List” and “Graph” of this measurement. Also, you can save this information data
with pressing the Save softkey.
