2-41
User Manual for DM3000 Ser
ies
Set Up RS-232 I/O Parameters
Press
Æ
I/O
Æ
RS232 , enter the menu shown below:
Figure 2-48
T
able 2-28 RS-232 P
arameter Function Menu
Explanation
Function Menu
Display
Explanation
Baud
300
.
.
38400
Set RS-232
baud ra
te as 300,
2400, 4800, 9600, 192
00 or
38400.
Pa
ri
t
y
None
Odd
Even
The parity check include: None,
Odd check, and Even check.
Save all changes, back to a higher
level menu.
90
92
