RIGOL Chapter 2 Front Panel Operations
2-44 DP800 User’s Guide
5. Set the IP Address
Please acquire a valid IP address from your network administrator firstly and set
the IP address manually in manual IP configuration mode.
The format of the IP address is nnn.nnn.nnn.nnn; wherein, the first nnn ranges
from 1 to 223 (except 127) and the other three range from 0 to 255.
Press IP Addr and use the numeric keyboard and direction keys to input the
desired IP address. This setting is stored in the non-volatile memory and the
instrument will load the IP address set automatically at the next power-on if
DHCP and Auto IP are set to “Off”.
6. Set the Subnet Mask
Please acquire a valid subnet mask from your network administrator firstly and
set the subnet mask manually in manual IP configuration mode.
The format of the subnet mask is nnn.nnn.nnn.nnn; wherein, the range of nnn is
from 0 to 255.
Press Sub Mask and use the numeric keyboard and direction keys to input the
desired subnet mask. This setting is stored in the non-volatile memory and the
instrument will load the subnet mask set automatically at the next power-on if
DHCP and Auto IP are set to “Off”.
7. Set the Gateway
Please acquire a valid gateway address from your network administrator firstly
and set the gateway manually in manual IP configuration mode.
The format of the gateway is nnn.nnn.nnn.nnn; wherein, the first nnn ranges
from 1 to 223 (except 127) and the other three range from 0 to 255.
Press Gateway and use the numeric keyboard and direction keys to input the
desired gateway address. This setting is stored in the non-volatile memory and
the instrument will load the gateway address set automatically at the next
power-on if DHCP and Auto IP are set to “Off”.
8. Set the DNS Server
Please acquire a valid DNS server address from your network administrator
firstly and set the DNS (Domain Name Service) address manually in manual IP
configuration mode.
The format of the DNS address is nnn.nnn.nnn.nnn; wherein, the first nnn
ranges from 1 to 223 (except 127) and the other three range from 0 to 255.
Press DNS Serv and use the numeric keyboard and direction keys to input the
desired address. This setting is stored in the non-volatile memory and the
